100 Rockwell Automation Publication 1734-UM013J-EN-P - July 2014
Chapter 5 Configure the Module in a GuardLogix Controller System
Values and States of Tags This table shows the values and states of the tags.
Data Description
Digital Input Data
Run Mode
STANDARD Indicates whether consumed data is actively being updated by a device that is in one of these
states:
• Run mode: 1 Idle State: 0
Connection Faulted
STANDARD Indicates the validity of the safety connection between the safety producer and the safety
consumer.
• Valid: 0 Faulted: 1
Safety Input Data
SAFETY Indicates the ON/OFF state of each input circuit.
• ON: 1 OFF: 0
Combined Safety Input Status
SAFETY An AND of the status of all input circuits.
• All circuits are normal: 1
• An error was detected in one or more input circuits: 0
Individual Safety Input Status
SAFETY Indicates the status of each input circuit.
• Normal: 1 Fault (Alarm): 0
Combined Safety Output Status
SAFETY An AND of the status of all safety output circuits.
• All circuits are normal: 1
• An error has been detected in one or more output circuits: 0
Individual Safety Output Status
SAFETY Indicates the status of each safety output circuit.
• Normal: 1 Fault (Alarm): 0
Muting Lamp Status
SAFETY Indicates the status when circuit T1 and T3 is configured as the muting lamp output.
• Normal: 1 Fault (Alarm): 0
Output Readback
STANDARD Monitors the presence of 24V on the output circuit. Readback is ON (1) if 24V is on output
terminal.
• ON: 1 OFF: 0
Individual Test Output Status
STANDARD Indicates the status of each of the test output circuits.
• Normal: 1 Fault (Alarm): 0
Input Power Error Bit Indicates field power supplied is within specification.
• Power error: 1 Power OK: 0
Output Power Error Bit Indicates field power supplied is within specification.
• Power error: 1 Power OK: 0
Digital Output Data
Safety Output Data
SAFETY Controls the safety output.
• ON: 1 OFF: 0
Standard Output Data
STANDARD Controls the test output when Test Output mode is set to a standard output.
• ON: 1 OFF: 0
