ControlNet Objects: Class Code 0x06 — Connection Manager Object D-9
Class Code 0x06 — Connection
Manager Object The Connection Manager Object is used to manage the establishment
and maintenance of communication connections.
Class Attributes
Instances
Instance Attributes
Attribute ID Access Rule Name Data Type Description
1
Get Revision UINT Revision of this object.
First revision, value=1.
2
Set Max Instance UINT Maximum instance number of an object
currently created in this class level of
the device.
4
Get Optional Attribute
List STRUCT of List of optional instance attributes used
in an object class implementation.
Number Attributes UINT Number of attributes in the optional
attribute list.
Optional Attributes ARRAY of
UINT
List of optional attribute numbers.
Instance Description
1 Connection Manager
Attribute ID Access Rule Name Data Type Description
1
Set OpenReqs UINT Number of Open Requests received
including Null Open Requests.
2
Set OpenFormat
Rejects UINT Number of open requests rejected by
this node due to format errors.
3
Set OpenResource
Rejects UINT Number of open requests rejected by
this node.
4
Set OpenOther Rejects UINT Number of open requests rejected or
timed out by downstream nodes.
5 Set CloseReqs UINT Number of close requests received.
6
Set CloseFormat
Rejects UINT Number of close requests rejected by
this node due to format errors.
7
Set CloseOther Rejects UINT Number of close requests received
rejected or timed out by downstream
nodes.
8
Set Conn Timeouts UINT Number of connections which have
been timed out by this node after they
were opened.
