Publication 1203-5.13 – February, 2002
ControlNet Objects: Class Code 0x0F — Parameter Object D-17
Common Services
Get_Attribute_All Response
At the class level, the order of the attributes returned in the “object/
services specific reply data” portion of the Get_Attribute_All
response is as follows:
At the instance level, the order of attributes returned in the
Get_Attributes_All response is as follows:
Service Code
Implemented for:
Service Name
Class Instance
0x01 Yes Yes Get_Attribute_All
0x0E Yes Yes Get_Attribute_Single
0x10 Yes Yes Set_Attribute_Single
Class Attribute ID Definition
1
Revision (low BYTE) Default = 1
Revision (high BYTE) Default = 0
2
Max Instance (low BYTE)
Max Instance (high BYTE)
8
Parameter class descriptor (low BYTE)
Parameter class descriptor (high BYTE)
9
Configuration Assembly Instance (low BYTE)
Configuration Assembly Instance (high BYTE)
10 Native Language Default = 0
Class Attribute ID Attribute Name and default Value
1 Parameter Value
2 Link Path Size
3 Link Path
4 Descriptor
5 Data Type
6 Data Size
7 Parameter Name String, default character count = 0
8 Units String, default character count = 0
9 Help String, default character count = 0
10 Minimum Value default = 0
11 Maximum Value default = 0
12 Default Value default = 0
13 Scaling Multiplier Default = 1
