Publication 1203-5.13 – February, 2002
E-2 Supported PCCC Messages
PCCC Error Response Codes The following table lists the PCCC error response codes.
Related documentation For more information on PCCC messages, refer to the DF1 Protocol
and Command Set Reference Manual, publication 1770-6.5.16.
Messages STS EXT STS Problem
All Messages
0x10 Illegal command or format. The adapter does not
support this command.
0x30 Remote station host is not present, disconnected,
or shutdown. The SCANport product is discon-
nected or cannot communicate for some other
reason.
All Messages
where
CMD=0x0F
0xF0 0x01 Illegal Address Format. A field has an illegal value
in a logical binary system address.
0xF0 0x02 Illegal Address Format. Not enough fields speci-
fied in a logical binary system address.
0xF0 0x03 Illegal Address Format. Too many fields specified
in a logical binary system address.
0xF0 0x06 Illegal Address. Address does not exist, or does
not point to something usable by this command.
0xF0 0x0A Request is too large. Transaction size plus word
address is too large. For example, a write of 10
elements to N50:248 would attempt to write data
beyond the end of the file.
0xF0 0x10 No Access. For example, your message tried to
write to a read-only location.
0xF0 0x11 Illegal data type information. For example, an
attempt to write floating point data to a numeric
[integer] file.
