Publication 1203-5.13 – February, 2002
ControlNet Objects: Class Code 0x10 — Parameter Group Object D-19
Class Code 0x10 — Parameter
Group Object The Parameter Group Object identifies and provides access to groups
of parameters in a device grouping. The Parameter Group Object
provides convenient access to related sets of parameters.
Class Attributes
Instances
The number of instances varies based on the number of groups in the
SCANport product. One additional group is added for the module.
Instance Attributes
Attribute ID Access Rule Name Data Type Description
1
Get Revision UINT Revision of this object. First revision,
value=1.
2
Get Max Instance UINT Maximum instance number of an object
currently created in this class level of
the device.
8
Set Native Language USINT Language ID for all STRING accesses.
0 = English
1 = French
2 = Spanish (Mexican)
3 = Italian
4 = German
5 = Japanese
6 = Portuguese
7 = Mandarin Chinese
Instance Description
1 – (n - 1) SCANport product groups
n Module group
➀
N is the value returned by a get from class attribute 2 (max
instance).
Attribute ID Access Rule Name Data Type Description
1
Get Group Name String SHORT_
STRING
A human-readable string representing
the group name (e.g., set-up, frequency
set).
Maximum number of characters = 16
2
Get Number of Members
in Group UINT Number of parameters in group.
3
Get 1st Parameter
Number in Group UINT Parameter instance number.
4
Get 2nd Parameter
Number in Group UINT Parameter instance number.
n
Get (n-2)th Parameter
Number in Group UINT Parameter instance number.
