Publication 1203-5.13 – February, 2002
ControlNet Objects: Class Code 0x01 — Identity Object
D-3
Instance Attributes
Common Services
Attribute ID
Access Rule
Name
Data Type
Description
1
Get
Vendor ID
UINT
Identification of each vendor by number.
1 = Allen-Bradley
2
Get
Device Type
UINT
Indication of general type of product.
0x69 = Sub-Component
0x6E = SCANport Device
3
Get
Product Code
UINT
Identification of a particular product of an
individual vendor.
0x0002 = 1336 PLUS 0.5 – 10 HP
0x0003 = 1336 PLUS 7.5 – 800 HP
0x0007 = 1336 PLUS II
0x0010 = 1336 FORCE w/ PLC Adapter
0x0011 = 2364F RGU
0x0012 = 1394 Motion Drive
0x0013 = 1557 Medium Voltage AC Drive
0x0014 =193 SMP-3
0x0015 = 150 SMC Dialog Plus
0x0017 = 1305 AC Drive
0x0018 = 1397 DC Drive
0x0019 = 1336 VSC
0x0020 = 1336T Force w/ Std Adapter
0x0022 = 1336 IMPACT
4
Get
Revision
STRUCT of
Revision of the item that this instance of
the Identity Object represents.
Value varies based on product.
Major Revision
USINT
Minor Revision
USINT
5
Get
Status
WORD
Summary status of product.
Value varies based on product.
6
Get
Serial Number
UDINT
Serial number of product.
Value varies based on product.
7
Get
Product Name
SHORT_
STRING
Human readable identification.
Value varies based on product.
Service Code
Implemented for:
Service Name
Class
Instance
0x01
Yes
Yes
Get_Attribute_All
0x05
Yes
Yes
Reset
0x0E
Yes
Yes
Get_Attribute_Single
