Overview
1-3
SCANport Products
Some SCANport products support one peripheral; others support up
to six peripherals. The table below lists SCANport products, the
number of peripherals each supports, and the minimum and
maximum I/O words allowed between the product and module.
Important: If you intend to use datalinks to communicate with and
control your SCANport product, verify that your SCANport product
supports datalinks before enabling them in the module.
Important: To connect multiple peripherals to a SCANport product,
a port expander may be required. Refer to your product’s
documentation for more information.
Product
Number of
Peripherals
Supported
I/O Words
Minimum
Maximum
1305 AC MICRO Drive
5
➀
0
10
1336 IMPACT™ Drive
6
➁
0
10
1336 PLUS AC Drive
6
➁
0
10
1336 PLUS II Drive
6
➁
0
10
1336 FORCE™ Drive
6
➁
0
10
1336 Line Regeneration Package
2
0
2
1394 AC Mult-Axis Motion Control
System
6
0
10
SMC Dialog Plus
1
0
2
SMP-3 Smart Motor Protector
2
0
2
1397 Digital DC Drive
5
0
10
1557 Medium Voltage Drive
5
0
10
2364 RGU DC Bus Regeneration
Front End
6
0
10
➀
Early versions of the 1305 AC MICRO Drive firmware may not support some types of
communications.
➁
Lower horsepower products may not support a sixth peripheral. Refer to your user
manual to verify that your product supports a sixth peripheral.
