ControlNet Objects: Class Code 0x0F — Parameter Object
Object Specific Services
Enumerated strings are human-readable strings that describe either a
bit or a value depending on the data type of instance attribute 1, the
Parameter Value. If the data type is a BYTE or WORD, the
enumerated string is a bit enumerated string. If the data type is INT or
UINT, the enumerated string is a value enumerated string. Any other
data type does not have enumerated strings.
The table below lists the parameters for the Get_Enum_String request
service.
•
If the string to be returned is a bit enumerated string, then the
enumerated string number represents a bit position and the
Get_Enum_String service returns a string from that bit.
•
If the string to be returned is a value enumerated string, then the
enumerated string number represents a value and the
Get_Enum_String service returns a string for that value.
The enumerated string is returned in the form of a SHORT_STRING
and is 16 characters long plus the preceding length byte.
14
Scaling Divisor Default = 1
15
Scaling Base Default = 1
16
Scaling Offset Default = 0
17
Multiplier Link Default = 0
18
Divisor Link Default = 0
19
Base Link Default = 0
20
Offset Link Default = 0
21
Decimal Precision Default = 0
Service Code
Implemented for:
Service Name
Class
Instance
0x4B
No
Yes
Get_Enum_String
Class Attribute ID
Attribute Name and default Value
Name
Data Type
Description of Attribute
Enumerated String Number
USINT
Number of enumerated string to retrieve (MAX value is 255).
