Publication 1203-5.13 – February, 2002
D-28 ControlNet Objects: Class Code 0x98 — SCANport Pass-Through Warning Object
Class Code 0x98 — SCANport
Pass-Through Warning Object The SCANport Pass-Through Warning Object provides information
on the product’s warning queue.
Class Attributes
Instance Attributes
Attribute ID Access Rule Name Data Type Description
0 Set Write Warning
Command BYTE Write Warning Command.
1 = Clear Warnings
2 = Clear Warning Queue
3 - Reset Product
1 Set Read Number of
Warning Queue Entries BYTE
Attribute ID Access Rule Name Data Type Description
0
Get Read Warning Queue
Entry Full/All Info STRUCT of
Warning Text ARRAY of BYTE 16 character string (no length
information, no terminating null).
Warning Code WORD Fault Code.
Warning Time Stamp STRUCT
BYTE 1/100 Second (0 – 99).
BYTE Second (0 – 59).
BYTE Minute (0 – 59).
BYTE Hour (0 – 23).
BYTE Day of Week (0 – 6).
➀
BYTE Date (1 – 31).
BYTE Month (1 – 12).
BYTE Year (0 – 99
➁
).
128
Get Warning Code and
Time Stamp STRUCT of
Warning Code WORD Fault Code.
Warning Time Stamp STRUCT of
BYTE 1/100 Second (0 – 99).
BYTE Second (0 – 59).
BYTE Minute (0 – 59).
BYTE Hour (0 – 23).
BYTE Day of Week (0 – 6).
➀
BYTE Date (1 – 31).
BYTE Month (1 – 12).
BYTE Year (0 – 99
➁
).
129
Get Read Warning Text
String Only ARRAY of BYTE 16 character string (no length
information, no terminating null).
➀
Sunday is a value of zero.
➁
Year is an offset from 1990.
