Rockwell Automation Publication 20Y-UM001E-EN-P - July 2014 15
Preface
Catalog Number Explanation
Position
1-3 4 5-7 8 9 10 11 12 13 14 15 16
20Y D 460 A 0 A N N A N A 0
a b c d e f g h i j k l
a
Drive
Code Type
20Y
PowerFlex AFE/
PowerFlex 700AFE
b
Voltage Rating
Code Input Voltage Phase
D 400/480V AC 3
F 600/690V AC 3
c1
400/480V Input
Code
Input
Amps
ND (HD)
kW at
400V
ND (HD)
HP at
480V
ND (HD)
Frame
Size
460
460
(385)
309
(258)
497
(416)
10
1K3
1300
(1150)
873
(772)
1404
(1242)
13
c2
600/690V Input
Code
Input
Amps
ND (HD)
HP at
600V
ND (HD)
kW at
690V
ND (HD)
Frame
Size
325
325
(240)
439
(324)
376
(278)
10
1K0 1030 ✦ 1390 ✦ 1193 ✦ 13
✦
There is no heavy duty rating for Frame 13 600/690V.
✻
Includes AFE power module, LCL Filter, Control Assembly,
motor-controlled circuit breaker, and precharge circuit in
a Rittal enclosure.
‡
Restricted to SSB. Includes AFE power module, LCL Filter,
and Control Assembly. Does not include circuit breaker or
precharge circuit.
Δ
Includes AFE power module, LCL Filter, Control Assembly,
Incoming circuit breaker, and precharge circuit in 2500
MCC Style enclosure. Frame 10 has 1250 Amp DC bus and
Frame 13 has 3000 Amp DC bus.
d
Enclosure
Code Type
Conformal
Coating
A
✻ IP21 Rittal Enclosure,
NEMA/UL Type 1
Yes
N
‡
IP00, Open-Chassis Yes
P
Δ
IP20, NEMA/UL Type 1
2500 MCC Style Enclosure
with Power Bus,
800 mm (31.5 in.) Deep,
Standard Cabinet Color
(RAL7032)
Yes
W
Δ
IP20, NEMA/UL Type 1
2500 MCC Style Enclosure
with Power Bus,
800 mm (31.5 in.) Deep,
CenterLine 2100 Gray
(ASA49)
Yes
e
HIM
Code Operator Interface Mount
0 No HIM AFE
f
Documentation
Code Documents Ship Carton
A User Manual Yes
♣
A 120V AC I/O option is not available.
g
Brake
Code w/Brake IGBT
N No
h
Brake Resistor
Code w/Resistor
N No
i
Equipment Type
Code Description
A AFE with Power Line Filter
j
Comm Slot
Code Communication Option
N None
k
I/O Option
Code Type I/O Volts
A ♣ Standard, with Outputs 24V DC
l
Feedback
Code Type Installed On
0 None N/A
