Supplemental Information Appendix A
Fusing and Circuit Breakers
for AFE in IP20 2500 MCC
Style Enclosure AC Input Fuse and Circuit Breaker Ratings
The tables in this section provide the recommended AC input line fuses and
circuit breakers. The AFE in a IP20 2500 MCC Style enclosure includes the
recommended AC input fusing and circuit breaker.
400/480 Volt AC Fusing and Circuit Breaker Ratings
600/690 Volt AC Fusing and Circuit Breaker Ratings
DC Bus Output Fuse Ratings
DC Bus Output fusing must be used for short circuit protection. The tables in
this section provide the ratings of the DC Bus Output fuses used for the AFE in a
IP20 2500 MCC Style enclosure.
465-800 Volt DC Fusing
640-1100 Volt DC Fusing
Frame
Size Fuse Rating Main Circuit Breaker Rating
Amps Bussman Type Amps ABB Type
10 800 A 170M6696 600 A T5L600BW
13 2200 A 170M7090 1600 A T8VBC3FC000000xx
Frame
Size Fuse Rating Main Circuit Breaker Rating
Amps Bussman Type Amps ABB Type
10 630 A 170M6694 400 A T5L400BW
13 1800 A 170M7532 1600 A T8VBC3FC000000xx
Frame
Size Fuse Rating
Amps Bussman Type
10 1100 A 170M6499
13 1100 A (2 per phase) 170M6499
Frame
Size Fuse Rating
Amps Bussman Type
10 630 A 170M6454
13 630 A (2 per phase) 170M6454
