126 Rockwell Automation Publication 20Y-UM001E-EN-P - July 2014
Appendix A Supplemental Information
Category Specification
Protection AFE Voltage Class 380/400V 480V 600V 690V
Bus Overvoltage Trip 911V DC 911V DC 1200V DC 1200V DC
Bus Undervoltage Shutoff/Fault 333VDC 333V DC 461V DC 461V DC
Heat Sink Thermistor Monitored by microprocessor overtemp trip
Ground Fault Protection Yes
Input Phase Loss Protection Yes
Input Overcurrent Protection Yes
Overtemperature Protection Yes
LCL Filter Overtemperature Protection Yes
Line Transients Up to 6000 volts peak per IEEE C62.41-1991
Control Logic Noise Immunity Showering arc transients up to 1500V peak
Ground Fault Trip DC bus-to-ground current exceeds par 082 [Ground I Lvl] value
Environment Altitude 1000 m (3300 ft) max. without derating
Max. Surrounding Air Temperature without
De-rating 0…40 °C (32…104 °F); Frame 13 600/690V AFE is rated at 35 °C. See
Derating Guidelines on page 127 for derating above 35 °C.
Storage Temperature (all constructions) –40…60 °C (–40…140 °F)
Atmosphere Important: The AFE must not be installed in an area where the
ambient atmosphere contains volatile or corrosive gas, vapors or dust.
If the AFE is not going to be installed for a period of time, it must be
stored in an area where it is not exposed to a corrosive atmosphere.
Relative Humidity 5…95% non-condensing
Shock (Non-operational) 15G peak for 11 ms duration
EN50178 / EN60068-2-27
Vibration 1 mm (0.039 in.) displacement, 1G peak
EN50178 / EN60068-2-6
Sound:
Frame 10
Frame 13 71 dB at 1 m (3.28 ft)
80 dB at 1 m (3.28 ft)
Electrical AC Input Voltage Tolerance ±10%
Frequency Tolerance 48…63 Hz
Input Phases Three-phase input provides full rating for all AFEs. The AFE cannot be
operated with single-phase input.
Displacement Power Factor 1.0 default across entire range
Efficiency 97.5% at rated amps, nominal line volts
Short Circuit Rating: AFE Frame 10 in IP20
AFE Frame 13 in IP20
AFE in IP21 or AFE IP00
100 kA for 400/480V unit; 65 kA for 600/690V unit
100 kA for 400/480V unit; 100 kA for 600/690V unit
Determined by AIC rating of installed fuse/circuit breaker
Control AFE Voltage Class 380/400V 480V 600V 690V
DC Output Voltage Range 462…702 583…842 700…932 802…1071
Method Sine-coded PWM
Carrier Frequency 3.6 kHz
Intermittent Overload:
Normal Duty
Heavy Duty 110% Overload capability for up to 1 minute
150% Overload capability for up to 1 minute (this heavy duty rating
does not apply to Frame 13 600/690V AFEs
Current Limit Capability Current Limit programmable from 20…150% of rated input current.
