Accessing parameter 39 - [accel time – Rockwell Automation 22-COMM-P PowerFlex Profibus Adapter User Manual
Page 71
Using Multi-Drive Mode
7-11
Example: The parameter messaging accesses the drive Parameter 39 -
[Accel Time] for Drive 0 to Drive 4 in Multi-Drive mode.
Accessing Parameter 39 - [Accel Time]
Module
IND (0 - 2 bits)
PNU
Drive 0 Single Drive
0 0 0
39
Drive 0-1 Multi Drive
0 0 1
39
Drive 0-2 Multi Drive
0 1 0
39
Drive 0-3 Multi Drive
0 1 1
39
Drive 0-4 Multi Drive
1 0 0
39
