Chapter
2
Installing the Adapter
This chapter provides instructions for installing the adapter in a
PowerFlex 40, PowerFlex 40P or PowerFlex 400 drive. This adapter can
also be installed in a DSI External Comms Kit. In this case, refer to the
22-XCOMM-DC-BASE Installation Instructions (publication
22COMM-IN001) supplied with the kit.
Before installing the adapter, verify that you have all required
equipment. See
Chapter 1 , Required Equipment .
To commission the adapter, you must set a unique node address and
check the data rate that is used by the network. (Refer to the
Glossary for
details about node addresses.)
Important: New settings are recognized only when power is applied to
the adapter. If you change a setting, cycle power.
Topic Page
Preparing for an Installation 2-1
Commissioning the Adapter 2-1
Connecting the Adapter to the Drive 2-5
Connecting the Adapter to the Network 2-8
Termination 2-11
Applying Power 2-11
Preparing for an Installation
Commissioning the Adapter
!
ATTENTION: Risk of equipment damage exists. The Profibus
adapter contains ESD (Electrostatic Discharge) sensitive parts that can
be damaged if you do not follow ESD control procedures. Static control
precautions are required when handling the adapter. If you are
unfamiliar with static control procedures, refer to Guarding Against
Electrostatic Damage, Publication 8000-4.5.2.
