Chapter
4
Configuring the Profibus Scanner
Profibus scanners are available from several manufacturers, including
SST. This chapter provides instructions on how to utilize the SST
Profibus configuration software tool to:
• Install the 22-COMM-P GSD file in the software tool library
• Configure the SST-PFB-SLC Profibus Scanner.
In this example, we will be configuring two PowerFlex 40 drives, to be
Station 1 and Station 2 on a Profibus network. This will be the
configuration used throughout the manual. Apart from the node address
and scanner mapping, they will have identical configurations. This
chapter describes the steps to configure a simple network like the
network in
Figure 4.1 .
Topic Page
Example Network 4-1
SST Profibus Configuration Software Tool 4-2
Installing 22-COMM-P GSD File in Software Tool Library 4-3
Configuring the SST-PFB-SLC Profibus Scanner 4-5
Example Network
