Installing the Adapter 2-3
Figure 2.2 Node Address Switch Settings (UP = OPEN = 1 = Off)
Switch Setting Node
SW 1 SW 2 SW 3 SW 4 SW 5 SW 6 SW 7 Addr.
0 0 0 0 0 0 0 0
1 0 0 0 0 0 0 1
0 1 0 0 0 0 0 2
1 1 0 0 0 0 0 3
0 0 1 0 0 0 0 4
1 0 1 0 0 0 0 5
0 1 1 0 0 0 0 6
1 1 1 0 0 0 0 7
0 0 0 1 0 0 0 8
1 0 0 1 0 0 0 9
0 1 0 1 0 0 0 10
1 1 0 1 0 0 0 11
0 0 1 1 0 0 0 12
1 0 1 1 0 0 0 13
0 1 1 1 0 0 0 14
1 1 1 1 0 0 0 15
0 0 0 0 1 0 0 16
1 0 0 0 1 0 0 17
0 1 0 0 1 0 0 18
1 1 0 0 1 0 0 19
0 0 1 0 1 0 0 20
1 0 1 0 1 0 0 21
0 1 1 0 1 0 0 22
1 1 1 0 1 0 0 23
0 0 0 1 1 0 0 24
1 0 0 1 1 0 0 25
… …
0 0 0 0 1 1 1 112
1 0 0 0 1 1 1 113
0 1 0 0 1 1 1 114
1 1 0 0 1 1 1 115
0 0 1 0 1 1 1 116
1 0 1 0 1 1 1 117
0 1 1 0 1 1 1 118
1 1 1 0 1 1 1 119
0 0 0 1 1 1 1 120
1 0 0 1 1 1 1 121
0 1 0 1 1 1 1 122
1 1 0 1 1 1 1 123
0 0 1 1 1 1 1 124
1 0 1 1 1 1 1 125
