Seam-loc 24 – Metal Sales Seam-Loc 24 Installation User Manual
Page 64
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 12/03
800.406.7387 (Corporate Office) • www.metalsales.us.com
63
SEAM-LOC 24
®
C
LIP
D
ETAIL
O
VER
R
IGID
I
NSULATION
Dekfast
Rigid Insulation
Floating Clip
Bearing Plate
Metal Deck
Seam-Loc 24 Panel
Vapor Barrier
Dekfast
Rigid Insulation
Floating Clip
Bearing Plate (flat)
Metal Deck
Seam-Loc 24 Panel
FLOATING SYSTEM WITH BEARING PLATE
FLOATING SYSTEM WITH BEARING PLATE
ISOMETRIC
