E94AYCCA communication manual (CANopen®)
Parameter reference
Parameters of the communication module for slot MXI1
126
L
EDS94AYCCA EN 5.0 - 06/2012
C13612
C13613
Parameter | Name:
C13612 | Resp. to CAN node guarding error
Data type: UNSIGNED_8
Index: 10963
d
= 2AD3
h
Response of master if the corresponding node guarding response is missing.
Selection list
(Lenze setting printed in bold)
1 Fault
2 Trouble
3 Quick stop by trouble
4 Warning locked
5 Warning
6 Information
0 No response
Subcodes
Lenze setting
Information
C13612/1
0: No response
Response to the absence of the node guarding response
for monitoring entry 1 ... 32
...
C13612/32
;
Read access ; Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C13613 | Resp. to CAN heartbeat error
Data type: UNSIGNED_8
Index: 10962
d
= 2AD2
h
Response if the corresponding heartbeat telegram is missing.
Selection list
(Lenze setting printed in bold)
1 Fault
2 Trouble
3 Quick stop by trouble
4 Warning locked
5 Warning
6 Information
0 No response
Subcodes
Lenze setting
Information
C13613/1
0: No response
Response to the absence of the heartbeat telegram for
monitoring entry 1 ... 32
...
C13613/32
;
Read access ; Write access CINH PLC STOP No transfer
Scaling factor: 1
