EDS94AYCCA EN 5.0 - 06/2012
L
113
E94AYCCA communication manual (CANopen®)
Parameter reference
Parameters of the communication module for slot MXI1
C13347
C13348
C13349
Parameter | Name:
C13347 | CAN heartbeat status
Data type: UNSIGNED_8
Index: 11228
d
= 2BDC
h
Status of node 1 ... 32
Selection list
(read only)
0 Unknown
4 Stopped
5 Operational
127 Pre-operational
Subcodes
Information
C13347/1
...
C13347/32
;
Read access Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C13348 | CAN status DIP switch
Data type: UNSIGNED_8
Index: 11227
d
= 2BDB
h
• The value "1" means that the CAN DIP switches have been recognised during power-on and a valid baud rate and
node address have been set.
• The value "0" means that either no CAN DIP switch or no valid setting has been recognised or that the setting has
been overwritten by code
Selection list
(read only)
Information
0 Setting not accepted
1 Setting accepted
;
Read access Write access CINH PLC STOP No transfer
Scaling factor: 1
Parameter | Name:
C13349 | CAN setting of DIP switch
Data type: UNSIGNED_8
Index: 11226
d
= 2BDA
h
CAN DIP switch setting during last power-on
Possible settings via DIP switches ( 33)
Display range
(min. value | unit | max. value)
0
255
Subcodes
Information
C13349/1
Node address
C13349/2
Baud rate:
0: 500 kbps
1: 250 kbps
2: 125 kbps
3: 50 kbps
4: 1 Mbps
5: 20 kbps
6: 10 kbit/s
14: 800 kbps
255: Automatic detection
;
Read access Write access CINH PLC STOP No transfer
Scaling factor: 1
