Lenze E94AYCCA - Manual (Page 116)

E94AYCCA communication manual (CANopen®)
Parameter reference
Parameters of the communication module for slot MXI1
116
L
EDS94AYCCA EN 5.0 - 06/2012
C13360
C13361
Parameter | Name:
C13360 | CAN telegram and error counter
Data type: UNSIGNED_16
Index: 11215
d
= 2BCF
h
• After mains connection, all counters start with "0".
• After the maximum value has been reached, it is started with "0" again.
Display range
(min. value | unit | max. value)
0 65535
Subcodes Information
C13360/1 Stuffing bit error counter
• More than five identical bits have been detected.
C13360/2 Format error counter
• CAN frame has not been observed.
C13360/3 Acknowledge error counter
• No node has confirmed the telegram.
C13360/4 Bit1 error counter
• "1" should be sent after bus arbitration, but "0" was
read.
C13360/5 Bit0 error counter
• "0" should be sent after bus arbitration, but "1" was
read.
C13360/6 CRC error counter
• Checksum check has indicated an error.
C13360/7 Tx telegram counter
• Telegrams received without errors.
C13360/8 Rx telegram counter
• Telegrams sent without errors.
; Read access Write access CINH PLC STOP No transfer Scaling factor: 1
Parameter | Name:
C13361 | CAN bus load
Data type: UNSIGNED_32
Index: 11214
d
= 2BCE
h
The display of the node peak load (subcodes 4 ... 6) can be reset by mains switching or via a "Reset node" command
(C00002 = 92).
Display range
(min. value | unit | max. value)
0 % 100
Subcodes Information
C13361/1 Current node load in Tx direction
C13361/2 Current node load in Rx direction
C13361/3 Current node load by faulty telegrams
C13361/4 Node peak load in Tx direction
C13361/5 Node peak load in Rx direction
C13361/6 Node peak load by faulty telegrams
; Read access Write access CINH PLC STOP No transfer Scaling factor: 1
