Lenze E84AYCER - Manual (Page 82)

E84AYCER communication manual (PROFINET)
Parameter reference
Parameters of the communication module
82
L
EDS84AYCER EN 2.0 - 11/2010
C13853
C13860
C13861
Parameter | Name:
C13853 | All words from standard device
Data type: UNSIGNED_16
Index: 10722
d
= 29E2
h
Display of the process data words 1 ... 16, which are transmitted from the controller to the IO controller.
Display range
(min. value | unit | max. value)
0 65535
Subcodes Information
C13853/1
...
C13853/16
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13860 | Settings
Data type: UNSIGNED_8
Index: 10715
d
= 29DB
h
Display range (min. value | unit | max. value)
0 255
Subcodes Information
C13860/1 Reserved
C13860/2 Number of process data words
C13860/3 Reserved
C13860/4 Reserved
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13861 | Bus status
Data type: BITFIELD_16
Index: 10714
d
= 29DA
h
Bit-coded display of current bus status
Value is bit-coded:
Bit 0 Initialised
Bit 1 Online
Bit 2 Connected
Bit 3 Address conflict
Bit 4 Hardware error
Bit 5 EEPROM error
Bit 6 Watchdog error
Bit 7 Protocol error
Bit 8 Profinet stack ok
Bit 9 Profinet stack not configured
Bit 10 Ethernet controller error
Bit 11 UDP stack error
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
