Lenze E84AYCER - Manual (Page 76)

E84AYCER communication manual (PROFINET)
Error messages
Possible causes and remedies
76
L
EDS84AYCER EN 2.0 - 11/2010
PROFINET: Invalid module configuration [0x01bc6430]
PROFINET: Record Parameter: Invalid read [0x01bc6501]
PROFINET: Record Parameter: Invalid write [0x01bc6502]
PROFINET: Invalid output data [0x01bc6503]
PROFINET: Data_Exchange status quit [0x01bc6531]
Response (Lenze setting in bold) Setting: not possible
None System fault : Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause Remedy
A module or submodule does not comply with the
configuration of the Siemens S7 engineering tool.
Check configuration.
Response (Lenze setting in bold) Setting: not possible
None System fault Fault Trouble Quick stop by trouble : Warning locked Warning Information
Cause Remedy
Invalid parameter read access Check configuration.
Response (Lenze setting in bold) Setting: not possible
None System fault Fault Trouble Quick stop by trouble : Warning locked Warning Information
Cause Remedy
Invalid parameter write access Check configuration.
Response (Lenze setting in bold) Setting: not possible
None System fault Fault Trouble Quick stop by trouble : Warning locked Warning Information
Cause Remedy
Output data invalid.
Connection to Siemens S7 has been interrupted.
Check cables and connections.
Plug in network cable at PROFINET terminal X256 or
X257.
Response (Lenze setting in bold) Setting: C13880/1 (; Adjustable response)
: None System fault ; Fault Trouble ; Quick stop by trouble ; Warning locked Warning ; Information
Cause Remedy
The data exchange via PROFINET has been terminated.
• See also chapter " Interruption of PROFINET
communication " ( 65) .
Check cables and connections.
Plug in network cable at PROFINET terminal X256 or
X257.
