E84aycer communication manual (profinet), Cs s s – Lenze E84AYCER User Manual
Page 27
EDS84AYCER EN 2.0 - 11/2010
L
27
E84AYCER communication manual (PROFINET)
Installation
Electrical installation
Tree via switches
[5-5]
Tree topology (C =IO controller, S = switch)
Switch / switch
[5-6]
Switch/switch topology (S = switch)
IO controller / IO device
[5-7]
Line topology (C = IO controller, D = IO device)
E94YCER006
C
S
S
S
E94YCER007
S
S
S
E94YCER008
D
D
D
D
C
