E84AYCER communication manual (PROFINET)
Commissioning
Setting the IP configuration
IP address ( C13000 )
 Valid IP addresses are defined in accordance with RFC 3330.

C13010 displays the IP address that is currently used.
Subnet mask ( C13001 )
 These subnet masks are permissible:
 C13012 displays the subnet mask that is currently used.
Gateway address ( C13002 )
 The gateway address is valid if the network address of the IP address and the gateway
address are identical.
 If the gateway address and the IP address are identical, gateway functionality is not
used.
 DHCP is not supported.

C13012 displays the gateway address that is currently used.
Example: IP address 192.168.0.1
(Sub)code
C13010/1 C13010/2 C13010/3 C13010/4
Value 192 168 0 1
Permissible subnet masks Value in C13001 [dec]
0.0.0.240 ... 128.255.255.255 4026531840 ... 4294967168
192.255.255.255 ... 248.255.255.255 4294967232 ... 4294967288
252.255.255.255 4294967292
Example: Subnet mask 192.255.255.255
(Sub)code
C13011/1 C13011/2 C13011/3 C13011/4
Value 192 255 255 255
Example: IP address 192.168.0.1
(Sub)code
C13012/1 C13012/2 C13012/3 C13012/4
Value 192 168 0 1
