E84AYCER communication manual (PROFINET)
Error messages
Possible causes and remedies
PROFINET: Station name error [0x01bc6532]
PROFINET: IP address error [0x01bc6533]
PROFINET: Stack init error [0x01bc6534]
PROFINET: Internal error [0x01bc6650]
Response (Lenze setting in bold) Setting: not possible
None System fault Fault Trouble Quick stop by trouble : Warning locked Warning Information
Cause Remedy
A station name that is not conform to PROFINET has
been defined.
Change the station name in accordance with the
PROFINET specification:
• 1 or several labels separated by ".".
• Max. length per label: 63 characters
• Max. total length: 240 characters
• Permissible characters: [a ... z], [0 ... 9], [.], [-]
• Labels must not begin or end with [-].
• Prohibited syntax:
–"n.n.n.n" (n = 0 ... 999)
–"port-xyz" (x, y, z = 0 ... 9)
–"port-xyz-abcde" (a, b, c, d, e, x, y, z = 0 ... 9)
Response (Lenze setting in bold) Setting: not possible
None System fault : Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause Remedy
An invalid IP address has been assigned by the IO
controller via PROFINET or has been set in code C13000 .
• Make sure that the IO controller has assigned a valid
IP address via PROFINET.
• Set a valid IP address.
Setting the IP configuration ( 38)
Response (Lenze setting in bold) Setting: not possible
None System fault : Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause Remedy
The stack cannot be initialised with the parameters
selected by the user. This may be due to a station name
which does not comply with the PROFINET specification.
Check and, if necessary, adapt PROFINET parameters:
Setting the IP configuration ( 38)
Setting the station name ( 36)
Response (Lenze setting in bold)
None System fault : Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause Remedy
Internal error Send device with error description to Lenze.
