EDS84AYCER EN 2.0 - 11/2010
L
79
E84AYCER communication manual (PROFINET)
Parameter reference
Parameters of the communication module
C13000
C13001
C13002
C13003
Parameter | Name:
C13000 | IP address
Data type: UNSIGNED_32
Index: 11575
d
= 2D37
h
Setting the IP address
Setting the IP configuration ( 38)
Setting range
(min. value | unit | max. value)
Lenze setting
0
4294967295 0
;
Read access ; Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13001 | Subnetwork mask
Data type: UNSIGNED_32
Index: 11574
d
= 2D36
h
Setting the subnet mask
Setting the IP configuration ( 38)
Setting range
(min. value | unit | max. value)
Lenze setting
0
4294967295 0
;
Read access ; Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13002 | Gateway address
Data type: UNSIGNED_32
Index: 11573
d
= 2D35
h
Setting the gateway address
Setting the IP configuration ( 38)
Setting range
(min. value | unit | max. value)
Lenze setting
0
4294967295 0
;
Read access ; Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13003 | Physical address
Data type: OCTET_STRING
Index: 11572
d
= 2D34
h
Display of the MAC-ID
Subcodes
Information
C13003/1
MAC ID: Station
C13003/2
MAC ID: Port1
C13003/3
MAC ID: Port2
;
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
