E84AYCER communication manual (PROFINET)
Technical data
General data and operating conditions
16
L
EDS84AYCER EN 2.0 - 11/2010
4 Technical data
4.1 General data and operating conditions
Field Values
Order designation E84AYCER
Communication profile PROFINET
Communication medium S/FTP (Screened Foiled Twisted Pair, ISO/IEC 11801 or EN 50173), CAT 5e
Interface RJ45: Standard Ethernet (in accordance with IEEE 802.3), 100Base-TX (Fast
Ethernet)
Network topology Tree, star, and line
Type of node IO device with real time (RT) communication properties
Number of device nodes Max. 255 in the subnetwork
Max. cable length 100 m
PUO ID number 0x0106
Device identification (Device ID) 0x8400
Baud rate 100 Mbps
Switching method "Store and forward"
Switch latency Approx. 125 μs at max. telegram length
Voltage supply External supply via separate power supply unit
• "+": V = 24 V DC (20.4 V - 0 % ... 28.8 V + 0 %), I = 140 mA
• "-": Reference potential for external voltage supply
Conformities, approvals • CE
• UL

"Inverter Drives 8400" hardware manual
This manual contains data on ambient conditions and the electromagnetic
compatibility (EMC) that also apply to the communication module.
