20836-01 Rev 04 Page 10-12
Once the file has been loaded the following message will be
displayed.
Figure 7 Load Configuration Complete Screen
If there is no file or the file name is not per the criteria in this section,
the following message will be displayed. In that case load the file per
the instructions in Advanced Functions as described in the following
sections.
Figure 8 Load Configuration Error Screen
To summarize the Load Configuration procedure:
Insert the memory stick in the USB Port.
When Figure 1 appears press ‘↓’ key.
When Figure 4 appears press ‘ENTER’.
When Figure 5 appears press ‘ENTER’.
When Figu
re 6 appears press ‘ENTER’.
When Figure 7 appears either remove the memory stick or
press ‘ENTER’ to return the menu.
If Figure 8 appears press ‘ENTER’ and scroll to the
‘ADVANCED FUNCTIONS’ menu to load the new configuration
file.
ERROR!
No configuration file found!
XXXX_LoadConfig.ini
