9.4.3
Flow/GVF Initial Setup
In order to conduct measurements, the ‘Basic Config’ setup must be
completed. If power goes off, this setup will remain in memory and
does not have to be re-entered.
Press any key except ‘EXIT’ on the keypad to enter the ‘Menu
Mode
’.
When ‘Basic Config’ menu is displayed on Line 1 of the display
press the ‘ENTER’ key to enter the options available under that
menu.
‘→Sensor Serial #’ will appear on Line 2 of the display. Press the
‘ENTER’ key and the current sensor band serial number entered in
the transmitter will be displayed on Line 4 of the display. The user
can then use the arrow keys (
↑ and ↓ to scroll through the values
and
← and → to change position) to enter the sensor serial
number. Once all digits are entered, press the
‘ENTER’ key to
save to memory. ‘→Sensor Serial #’ will again be displayed on
Line 2.
Next, press the
↓ key to scroll to the ‘Pipe Size’ menu on Line 2.
Press the
‘ENTER’ key to access the options available under that
menu. Note: it is necessary to select only one of the following
options.
The first choice on the
‘Pipe Size’ menu is ‘→ID / Wall’ shown on
Line 3 of the display. If this value is known it can be entered here.
Press the
‘ENTER’ key and the current saved inner diameter and
wall thickness will be shown on Line 4 of the display. Use the
arrow keys (
↑ and ↓ to scroll through the values and ← and → to
change character) to enter the pipe inner diameter. Units can be
inches or millimeters. Once all digits are entered, press the
‘ENTER’ key to save the value to memory.
The second choice on the
‘Pipe Size’ menu is ‘Size/Sched’ (pipe
Size / Schedule). If this value is known press the
‘ENTER’ key.
Use the arrow keys to enter the values and then press the
‘ENTER’ key to save to memory.
The third choice on the
‘Pipe Size’ menu is ‘OD / Wall’ displayed
on Line 3. Use the arrow keys (
↑ and ↓ to scroll through the values
and
← and → to change character) to enter the pipe inner
diameter. Units can be inches or millimeters. Once all digits are
entered, press the
‘ENTER’ key to save the value to memory.
Following the entering of ‘Pipe Size’ press the ‘BACK’ key and
‘→Pipe Size’ will be displayed on Line 2. At this point the user can
either press the
‘ENTER’ key to re-enter the ‘Pipe Size’ menu or
press the
↓ key to move to the next menu item.
