AiM MyChron3 XG Log User Manual
Dear mychron 3 plus/gold/gold xg owner

Dear MyChron 3 Plus/Gold/Gold XG Owner
Your MyChron 3 Plus/Gold/Gold XG represents the newest generation of Aim
data acquisition systems for car/bike racing that provide the driver with a wide,
easy to use and multifunctional display.
MyChron 3 Plus/Gold/Gold XG monitors and displays RPM, four analog inputs
(temperatures and pressures for Plus version, temperature, pressures,
potentiometers, Lambda sond for Gold versions), speed, gear number and lap
(split) times. It has a backlight, which can be switched on during night racing, and
a huge internal flash memory (512 kbyte for Plus version and 2 Mbyte for Gold
ones) which guarantees the capacity to record up to 315 laps. The gauge is
equipped with an USB port, used to interface the instrument with a PC. The new
software Race Studio 2 will allow you to easily configure the instrument, to
download data to a PC and to analyse them. Finally, the internal lateral G-force
sensor (standard equipment for Gold CAR versions) or the external gyroscope
(optional equipment for Gold BIKE versions) will allow you the ability to create a
circuit map, in order to correlate your data to your track position.
Our Customer Service is available every day from 9 to 5 and at most all the major
races throughout the country to provide you with personal service. If you have any
questions, need help, or want to give us feedback, please call us or visit our
webs
Thank you for your MyChron 3 Plus/Gold/Gold XG purchase.
1
Document Outline
- Table of contents
- Getting Started with MyChron 3 Plus/Gold/Gold XG
- MyChron 3 Plus/Gold/Gold XG and its parts
- How to install MyChron 3 Plus/Gold/Gold XG
- On track
- MyChron 3 Plus/Gold/Gold XG and the computer
- Configuration via software
- How to download a test
- How to use Race Studio Analysis
- MyChron 3 Plus/Gold/Gold XG quick reference guide
