MyChron 3 Plus/Gold/Gold XG and its parts
Before installing MyChron 3 Plus/Gold/Gold XG, please read carefully these
installation instructions.
It is very important that your MyChron 3 Plus/Gold/Gold XG is correctly
installed to capture consistent and accurate data. Incorrect installation may
result in system malfunction.
In the following drawing it is represented your MyChron 3 Gold display unit: in
the middle of the picture it is visible the wide display, in the lower part there is the
keyboard, on the left and on the right there are 4 coloured alarm led (labelled from
AL.1 to AL4) and, in the upper part, you can find the gear number display and 10
fully configurable RPM led.
In the following pages it will be described the different parts of MyChron 3
Plus/Gold/Gold XG system.
