SDRAM Controller
CS4953x4/CS4970x4 System Designer’s Guide
5.1.1 SDRAM Controller Interface
The physical interface of the SDRAM controller consists of 16 data pins (SD_DATA[15:0]), 13 address
pins (SD_ADDR[12:0]), 2 bank address pins (SD_BA[1:0]), and 9 control pins (SD_CS, SD_WE,
SD_DQM1, SD_DQM0, SD_CAS, SD_RAS, SD_CLKOUT, SD_CLKIN, SD_CLKEN). SD_CS is the
SDRAM chip select pin. The address and data pins are shared with the Flash interface. The CS4953x4/
CS4970x4 supports SDRAMs from 2 Mbytes to 64 Mbytes with various row, bank, and column
configurations. The size can be configured in the DynamicConfig0 register listed in
. Timing
parameters of the SDRAM port can be configured to meet various SDRAM requirements as described in
. The default timing parameters have been chosen and tested to meet the requirements of Hynix
HY57V641620HG-H. By default, the SDRAM port is configured for 64 Mbits with 4 banks, 12 rows, and 8
columns with a RAS and CAS latency of 3.
Note:When connected to a 16 Mbit SDRAM, the CS4953x4/CS4970x4 uses only SD_BA0 for bank
selection.
5.1.2 SDRAM Interface Signals
shows the signal names, descriptions, and pin number of the signals associated with the
external SDRAM memory control port on the CS4953x4/CS4970x4 chip.
Table 5-1. SDRAM Interface Signals
Signal Name
Signal Description
LQFP-144
Pin #
LQFP-128
Pin #
Pin Type
SD_CLKOUT
SDRAM clock output. This output is tri-stated when
SDRAM interface is not used.
51
80
Output
SD_CLKIN
SDRAM Clock input
Connects to trace from SDRAM device CLKIN pin.
52
81
Input
SD_CLKEN
SDRAM Clock Enable Output
53
82
Output
SD_RAS
SDRAM Row Address Strobe
80
109
Output
SD_CAS
SDRAM Column Address Strobe
79
108
Output
SD_CS
SDRAM Chip Select
81
110
Output
SD_DQM0
SDRAM Data Mask 0
28
57
Output
SD_DQM1
SDRAM Data Mask 1
50
79
Output
SD_WE
SDRAM Write Enable
78
107
Output
SD_A0
SDRAM Address 0
72
102
Output
SD_A1
SDRAM Address 1
71
101
Output
SD_A2
SDRAM Address 2
70
99
Output
SD_A3
SDRAM Address 3
68
97
Output
SD_A4
SDRAM Address 4
67
96
Output
SD_A5
SDRAM Address 5
64
93
Output
SD_A6
SDRAM Address 6
62
91
Output
SD_A7
SDRAM Address 7
61
90
Output
SD_A8
SDRAM Address 8
59
88
Output
SD_A9
SDRAM Address 9
58
87
Output
