CS4953
x4/CS497
0x4 System Desig
ner’s Gu
ide
93 121
RESET
Chip Reset 3.3V (5V tol) In
94 122 GNDIO6 I/O ground 0V PWR
95 123 GPIO33 General Purpose Input/Output SCP1_MOSI
SPI Mode Master Data Output/Slave
Data Input
3.3V (5V tol) BiDir IN
96 - GPIO32 General Purpose Input/Output 1. SCP1_CS
2. IOWAIT
1. SPI Chip Select
2. SRAM Hold-Off Handshake
3.3V (5V tol) BiDir IN
97 124 GPIO34 General Purpose Input/Output
1. SCP1_MISO
2. SCP1_SDA
1. SPI Mode Master Data Input/Slave
Data Output
2. I 2 C Mode Master/Slave Data IO
3.3V (5V tol) BiDir/OD IN
98 125 VDD6 Core power supply voltage 1.8V PWR
99 126 GPIO35 General Purpose Input/Output SCP1_CLK SPI/I
2
C Control Port Clock 3.3V (5V tol) BiDir/OD IN
100 - GPIO36 General Purpose Input/Output SCP1_IRQ
Serial Control Port Data Ready
Interrupt Request
3.3V (5V tol) BiDir/OD IN
101 127 GNDD6 Core ground 0V PWR
102 - GPIO37 General Purpose Input/Output 1. SCP1_BSY
2. PCP_BSY
1. Serial Control Port 1 Input Busy
2. Parallel Control Port Input Busy
3.3V (5V tol) BiDir/OD IN
- 128 GPIO37 General Purpose Input/Output 1. SCP1_BSY 1. Serial Control Port 1 Input Busy 3.3V (5V tol) BiDir/OD IN
103 - GPIO38 General Purpose Input/Output
1. PCP_WR
2. PCP_DS
3. SCP2_CLK
1. Parallel Port Write Select (Intel
Mode)
2. Parallel Port Data Strobe (Motorola
and Multiplexed Mode)
3. SPI/I 2 C Control Port Clock
3.3V (5V tol) BiDir/OD IN
- 1 GPIO38 General Purpose Input/Output 1. SCP2_CLK 1. SPI/I
2
C Control Port Clock 3.3V (5V tol) BiDir/OD IN
104 - GPIO39 General Purpose Input/Output
1. PCP_CS
2. SCP2_CS
1. Parallel Port Chip Select (Intel/
Motorola/Multiplexed Mode)
2. SPI Chip Select
3.3V (5V tol) BiDir IN
105 - GPIO11 General Purpose Input/Output
1. PCP_A3
2. PCP_AS
3. SCP2_MISO
4. SCP2_SDA
1. Parallel Control Port Address Bit 3
2. Parallel Control Port Address
Strobe
3. SPI Mode Master Data Input/Slave
Data Output
4. I 2 C Mode Master/Slave Data IO
3.3V (5V tol) BiDir/OD IN
- 2 GPIO11 General Purpose Input/Output
1. SCP2_MISO
2. SCP2_SDA
1. SPI Mode Master Data Input/Slave
Data Output
2. I
2
C Mode Master/Slave Data IO
3.3V (5V tol) BiDir/OD IN
Table P-10. CS4970x4 Pin Assignments (Continued) for 144-Pin and 128-Pin Packages (Continued)
LQFP-
144
Pin #
LQFP-
128
Pin #
Function 1
(Default)
Description of Default Function Secondary Functions Description of Secondary
Functions
Pwr Type
Reset
State
