DSP Condenser Runtime Application
CS4953x4/CS4970x4 System Designer’s Guide
DS810UM6 Copyright 2013 Cirrus Logic, Inc 9-1
Chapter 9
Using Runtime Condenser
9.1 DSP Condenser Runtime Application
9.1.1 Usage
9.1.1.1 Standard Launch
The DSP Condenser Runtime is launched from the DSP Condenser application. The DSP Condenser
application provides the .uld information to the runtime application. Use the following procedure.
1. Run DSP Condenser.
2. Create a flash DSP image using the DSP Condenser application as shown in Figure 9-1 .
Figure 9-1. DSP Condenser Wizard Menu Items
3. Wait for the image to finish building as shown in Figure 9-2 .
Figure 9-2. Flash Image Build Log
4. Flash the image using “Program flash on board” as shown in Figure 9-3 .
