Cirrus Logic CS4970x4 User Manual
Page 36
DS810
UM6
C
op
yri
ght 2
013
Ci
rru
s
Lo
gic
P
-25
CS49
53x4 Pin Assign
me
nts
CS4953
x4/CS497
0x4 System Desig
ner’s Gu
ide
108
-
GPIO41
General Purpose Input/
Output
1. PCP_IRQ
2. SCP2_IRQ
1. Parallel Control Port Data Ready
Interrupt Request
2. Serial Control Port Data Ready
Interrupt Request
3.3V (5V
tol)
BiDir/OD
IN
Y
109
-
GPIO9
General Purpose Input/
Output
1. PCP_A1
2. PCP_A9
1. Parallel Control Port Address Bit 1
2. Parallel Control Port Address Bit 9
3.3V (5V
tol)
BiDir
IN
Y
-
4
GPIO9
General Purpose Input/
Output
1. SCP1_IRQ
1. Serial Control Port Data Ready
Interrupt Request
3.3V (5V
tol)
BiDir
IN
Y
110
-
GPIO8
General Purpose Input/
Output
1. PCP_A0
2. PCP_A8
1. Parallel Control Port Address Bit 0
2. Parallel Control Port Address Bit 8
3.3V (5V
tol)
BiDir
IN
Y
-
5
GPIO8
General Purpose Input/
Output
1. SCP2_IRQ
1. Serial Control Port Data Ready
Interrupt Request
3.3V (5V
tol)
BiDir
IN
Y
111
-
GPIO7
General Purpose Input/
Output
1. PCP_D7
2. PCP_AD7
1. Parallel Control Port Data Bus
2. Parallel Control Port Multiplexed
Address and Data Bus
3.3V (5V
tol)
BiDir
IN
Y
-
6
GPIO7
General Purpose Input/
Output
1. SCP1_CS
2. IOWAIT
1. SPI Chip Select
2. SRAM Hold-Off Handshake
3.3V (5V
tol)
BiDir
IN
Y
112
-
GPIO6
General Purpose Input/
Output
1. PCP_D6
2. PCP_AD6
1. Parallel Control Port Data Bus
2. Parallel Control Port Multiplexed
Address and Data Bus
3.3V (5V
tol)
BiDir
IN
Y
-
7
GPIO6
General Purpose Input/
Output
1. SCP2_CS
1. SPI Chip Select
3.3V (5V
tol)
BiDir
IN
Y
113
8
VDDIO7
I/O power supply voltage
3.3V
PWR
114
-
GPIO5
General Purpose Input/
Output
1. PCP_D5
2. PCP_AD5
1. Parallel Control Port Data Bus
2. Parallel Control Port Multiplexed
Address and Data Bus
3.3V (5V
tol)
BiDir
IN
Y
115
-
GPIO4
General Purpose Input/
Output
1. PCP_D4
2. PCP_AD4
1. Parallel Control Port Data Bus
2. Parallel Control Port Multiplexed
Address and Data Bus
3.3V (5V
tol)
BiDir
IN
Y
116
9
GNDIO7
I/O ground
0V
PWR
117
-
GPIO3
General Purpose Input/
Output
1. PCP_D3
2. PCP_AD3
1. Parallel Control Port Data Bus
2. Parallel Control Port Multiplexed
Address and Data Bus
3.3V (5V
tol)
BiDir
IN
Y
-
10
GPIO3
General Purpose Input/
Output
3.3V (5V
tol)
BiDir
IN
Y
118
-
GPIO2
General Purpose Input/
Output
1. PCP_D2
2. PCP_AD2
1. Parallel Control Port Data Bus
2. Parallel Control Port Multiplexed
Address and Data Bus
3.3V (5V
tol)
BiDir
IN
Y
Table P-11. CS4953x4 Pin Assignments (Continued) for 144-Pin and 128-Pin Packages (Continued)
LQFP-
144
Pin #
LQFP-
128
Pin #
Function 1
(Default)
Description of Default
Function
Secondary Functions
Description of Secondary
Functions
Pwr
Type
Reset
State
Pullup
at
Reset
