138 30 DAI1_LRCLK
PCM Audio Input Sample Rate (Left/
Right) Clock
DSD4 DSD Audio Input Data 4 3.3V (5V tol) In
139 31 GNDIO8 I/O ground 0V PWR
140 - GPIO42 General Purpose Input/Output
1. DAI2_LRCLK
2. BDI_REQ
3. PCP_IRQ
4. PCP_BSY
1.PCM Audio Input Sample Rate
Clock
2. Bursty Data Input Request
3. Parallel Control Port Data Ready
Interrupt Request
4. Parallel Control Port Input Busy
3.3V (5V tol) BiDir/OD IN
- 32 GPIO42 General Purpose Input/Output
1. DAI2_LRCLK
2. BDI_REQ
3.PCP_IRQ
4.PCP_ BSY
1.PCM Audio Input Sample Rate
Clock
2. Bursty Data Input Request
3. Parallel Control Port Interrupt
4. Parallel Port Bus
3.3V (5V tol) BiDir/OD IN
141 33 GPIO43 General Purpose Input/Output
1. DAI2_SCLK
2. BDI_CLK 1.PCM Audio Input Bit Clock
2. Bursty Data Input Bit Clock
3.3V (5V tol) BiDir IN
142 34 DAI2_DATA PCM Audio Input Data
1. DAI1_DATA4
2. DSD5
3. BDI_DATA
1. PCM Audio Input Data 4
2. DSD Audio Input Data 5
3. Bursty Data Input Data
3.3V (5V tol) In
143 - GPIO27 General Purpose Input/Output 3.3V (5V tol) BiDir IN
144 - GPIO26 General Purpose Input/Output 3.3V (5V tol) BiDir IN
- 35 GPIO26 General Purpose Input/Output
1. DAO2_DATA3
2. XMTB
3. UART_TX_ENABLE
1. Digital Audio Output 3.
2. Outputs IEC60958/61937 format
bi-phase mark encoded S/PDIF data
3. Enable the UART_TX pin
3.3V (5V tol) BiDir IN
Table P-10. CS4970x4 Pin Assignments (Continued) for 144-Pin and 128-Pin Packages (Continued)
LQFP-
144
Pin #
LQFP-
128
Pin #
Function 1
(Default)
Description of Default Function Secondary Functions Description of Secondary
Functions
Pwr Type
Reset
State
