RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC400e/Persona C30e/M30e Card Printer User Guide (Rev. 1.1) 6-92
Refer to the previous procedure.
6 Define another area by clicking the Defined Area up arrow. (Note: Another .2" x .2" /
5mm x 5mm area will appear in the lower left-hand corner. This is the location in which
all newly defined areas will first appear.)
7
• Use the Defined Area arrows to navigate back and forth from area to area. (Note:
The active area will always be highlighted with a dotted outline. Up to 5 areas can
be defined.)
• New areas are always created in the same position with the same size so it is
recommended to move or resize them as they are created.
• All five defined or undefined areas can be added without moving the previous one
to another location. The up arrow on the Defined Area control can be activated
five times in a row and there are five areas added. After five areas are added there
appears to be only one until you move each one to a different location.
8 Delete an area by using the Defined Area arrows to select the area and clicking
Delete. (Note: If all areas are deleted, the K Panel Resin options will automatically be
deselected.)
