DTC400e/Persona C30e/M30e Card Printer User Guide (Rev. 1.1) 6-30
Using the Overlay Heat (O) option
Use this option to control the amount of heat the Printer uses when printing with the overlay
panel of a Ribbon. (Note: This control can be helpful for fine-tuning the transfer of overlay
onto the card.)
Step Procedure
1 Move the slide to the left to cause less heat to be used in the printing
process. (Note: Certain card types may need additional heat for better
transfer of the overlay material.)
OR
Move the slide to the right to cause more heat to be used.
