HID DTC400E/C30E/M30E User Guide - Manual (Page 152)

RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC400e/Persona C30e/M30e Card Printer User Guide (Rev. 1.1) 6-28
Using the Image Color tab (DTC400e/C30e/M30e)
Step Procedure
1 Select Algebraic and then use this option to control the Contrast and Gamma
of the printed image, as well as the individual color balance of Yellow, Magenta
and Cyan. (Note: In most cases, the default settings of these options will
suffice.)
2 Control the overall darkness and lightness of the printed image by adjusting the
Dye-Sub Intensity slider.
• Move the slide to the left to cause less heat to be used in the printing
process, thus generating a lighter print.
• Move the slide to the right to cause more heat to be used, thus generating a
darker print. (Note: This slide only affects those images printed with dye-
sublimation Ribbon panels (YMC).)
C30e
M30e
