RESTRICTED USE ONLY

Fargo Electronics, Inc.

DTC400e/Persona C30e/M30e Card Printer User Guide (Rev. 1.1)

6-51

Using the Bit Density dropdown list

Use this option to customize the Bit Recording Density (Bits per Inch) used to encode the
magnetic data on the currently selected track.

The default ISO Standard selections for this option are as follows:

Step

Procedure

1 Select

75 BPI to change the bits per inch to 75 BPI. (Note: This is the

default for Track 2.)

OR

Select 128 BPI to change the bits per inch to 128 BPI.

OR

Select 210 BPI to change the bits per inch to 210 BPI. (Note: This is the
default for Tracks 1 and 3.)

OR

Select Custom BPI, which enables the custom BPI text box. (Note: The
lower limit is 75 and upper limit is 210.)
