DTC400e/Persona C30e/M30e Card Printer User Guide (Rev. 1.1) 6-23
Using the Split 1 Set of Ribbon Panels option
Use this option to provide the most economical means of printing a dual-sided card since a
single set of Ribbon Panels will be split to print both the front and backsides of a card.
Step Procedure
1 Select this option to automatically print full-color on the front of a card and resin
black on the back of a card (using either of the Full-color YMCKO or YMCKOK
Print Ribbons).
• If using the YMCKO Ribbon type, the front of the card is printed with the
Ribbon's YMC Panels and the back is printed with the K Panel, and the O
Panel is printed on the front.
• If using the YMCKOK Ribbon type, the front of the card is printed with the
YMCKO Panels and the back is printed with the second K Panel.
(Note #1: This option is automatically enabled when the YMCKOK Ribbon type
is selected.)
