Figure 41: installing the rack mount screws – Allied Telesis SwitchBlade x3112 User Manual
Page 88
Chapter 3: Installing the Chassis in an Equipment Rack
88
Figure 41. Installing the Rack Mount Screws
5. Tighten all eight screws to secure the chassis to the equipment rack,
Allied Telesis recommends tightening the screws to 10 inch-lbs.
6. Go to “Removing the Shipping Brace” on page 89.
First 2 screws installed
Bottom Screw Slot
Center Screw
Top Screw
Bottom Screw Slot
Center Screw Slot
Top Screw Slot
Slot
Slot
