SwitchBlade x3112 Installation Guide

45

AT-SBx31GT40

Line Card

The LEDs for the ports on the AT-SBx31GT40 Line Card are found on the
RJ point 5 cable connectors. The LEDs are shown in Figure 21.

Figure 21. Port LEDs on an RJ Point 5 Cable Connector for the AT-

SBx31GT40 Line Card

Only the left LED on a connector is active. Refer to Figure 22. It displays
link and activity status information about a port, as described in Table 6 on
page 46. The right LED is not used.

Figure 22. Link/Activity LED on an RJ Point 5 Cable Connector for the AT-

SBx31GT40 Line Card

LEDs

L/A LEDs
