Figure 134: removing the plastic cover – Allied Telesis SwitchBlade x3112 User Manual
Page 176

Chapter 7: Powering On the Chassis
176
3. Using a #1 Phillips-head screwdriver, remove the two screws that
secure the plastic cover over the positive and negative terminals and
remove the plastic cover from the power supply, as shown in
Figure 134. You may need to lift the locking handle slightly to access
the bottom screw.
Figure 134. Removing the Plastic Cover
Note
The plastic cover is not used with the right angle terminals.
4. Use a #3 Phillips-head screwdriver to remove the two screws from the
positive and negative terminals, as shown in Figure 135 on page 177.
