©2008 Advanced Micro Devices, Inc. OCHI USB 1.1 and EHCI USB 2.0 Controllers
AMD SB600 Register Reference Manual Proprietary Page 79
USBLEGCTLSTS – RW - 32 bits - [PCI_Reg : EECP + 04h]
Field Name Bits Default Description
SMI on OS Ownership
Enable 13 0b When this bit is a one AND the OS Ownership Change bit is
one, the host controller will issue an SMI.
SMI on PCI Command
Enable 14 0b When this bit is one and SMI on PCI Command is one, then
the host controller will issue an SMI.
SMI on BAR Enable 15 0b When this bit is one and SMI on BAR is one, then the host
controller will issue an SMI.
SMI on USB Complete 16 0b Shadow bit of USB Interrupt (USBINT) bit in the USBSTS
register. To set this bit to a zero, system software must
write a one to the USB Interrupt bit in the USBSTS register.
Read Only.
SMI on USB Error 17 0b Shadow bit of USB Error Interrupt (USBERRINT) bit in the
USBSTS register. To set this bit to a zero, system software
must write a one to the USB Error Interrupt bit in the
USBSTS register.
Read Only.
SMI on Port Change
Detect. 18 0b Shadow bit of Port Change Detect bit in the USBSTS
register. To set this bit to a zero, system software must write
a one to the Port Change Detect bit in the USBSTS register.
Read Only.
SMI on Frame List Rollover 19 0b Shadow bit of Frame List Rollover bit in the USBSTS
register. To set this bit to a zero, system software must write
a one to the Frame List Rollover bit in the USBSTS register.
Read Only.
SMI on Host System Error 20 0b Shadow bit of Host System Error bit in the USBSTS register.
To set this bit to a zero, system software must write a one to
the Host System Error bit in the USBSTS register.
Read Only.
SMI on Async Advance 21 0b Shadow bit of the Interrupt on Async Advance bit in the
USBSTS register. To set this bit to a zero, system software
must write a one to the Interrupt on Async
Advance
bit in the USBSTS register.
Read Only.
Reserved. 28:22 These bits are reserved and must be set to zero.
SMI on OS Ownership
Change 29 0b This bit is set to one whenever the HC OS Owned
Semaphore
bit in the USBLEGSUP register transitions from
1 to 0 or 0 to 1.
SMI on PCI Command 30 0b This bit is set to one whenever the PCI Command Register
is written.
SMI on BAR R/WC 31 0b This bit is set to one whenever the Base Address Register
(BAR) is written.
2.2.3.2 Host Controller Capability Registers (MEM_Reg)
This block of registers is memory-mapped. Access address is equal to offset address plus base address defined in
BAR[PCI_Reg : 10h].
Registers Name Offset Address
Capability Register Length - CAPLENGTH 00h
Reserved 01h
Host Controller Interface Version – HCIVERSION 02h
Structural Parameters – HCSPARAMS 04h
Capability Parameters - HCCPARMAS 08h
Companion Port Route Description – HCSP-PORTROUTE 0Ch
