AC ’97 Controller Functional Descriptions
AMD SB600 Register Reference Manual
Proprietary
Page 222
Counter - R - 32 bits - [MEM_Reg: 18h]
Field Name
Bits
Default
Description
Slot Counter
3:0
0h
The current slot number (0-12) which the AC97
controller handling.
Reserved 7:4
0h
Bit Clock Counter
12:8
00h
For the tag slot, the value changes from 0 to F. For
other slots the value changes from 0 to 20.
Reserved 31:13
00000h
Counter Register:
Input FIFO Threshold - RW - 32 bits - [MEM_Reg: 1Ch]
Field Name
Bits
Default
Description
Input Threshold
4:0
00h
Threshold value for the Input Channel's FIFOs. (FIFO
size 16x20)
Reserved 31:5
0000000h
Input FIFO Threshold Register: Input DMA's FIFOs threshold value.
Input DMA Link List Pointer - RW - 32 bits - [MEM_Reg: 20h]
Field Name
Bits
Default
Description
in DMA LL ptr en
0
0b
Input DMA Link List Pointer enable
in DMA LL Pointer
31:1
0000_0000h Pointer to the start of the Link List - to the first DT.
Input DMA Link List Pointer Register:
Input DMA DT Start - R - 32 bits - [MEM_Reg: 24h]
Field Name
Bits
Default
Description
in DMA DT start
31:0
0000_0000h Pointer to the start of data associated with current DT
for the input DMA
Input DMA Discrete Table (DT) Start Pointer Register.
Input DMA DT Next - R - 32 bits - [MEM_Reg: 28h]
Field Name
Bits
Default
Description
in DMA DT next
31:0
0000_0000h Pointer to the next DT for the input DMA
Input DMA DT Next Pointer Register.
Input DMA DT Current - R - 32 bits - [MEM_Reg: 2Ch]
Field Name
Bits
Default
Description
in DMA DT current
31:0
0000_0000h Pointer to the currently accessing memory address for
the input DMA
Input DMA DT Current Pointer Register.
Input DMA DT Size & FIFO Info - R - 32 bits - [MEM_Reg: 30h]
Field Name
Bits
Default
Description
in DMA DT size
15:0
0000h
Data size of DT for input DMA.
in FIFO Used
20:16
00h
Number of filled FIFO entries of input DMA.
in FIFO Free
25:21
06h
Number of free FIFO entries of input DMA.
in DMA State
28:26
0h
Current state of the in DMA
Reserved 31:20
000h
Input DMA DT Size & FIFO info Register: Size of data associated with DT for input channels and number of FIFO
entries free and used for the input channels.
