LdtAgpTimeCntl – RW – 8 bits – [PM_Reg:8Ah]
Field Name
Bits
Default
Description
LdtAgpTimeCntl register for ACPI C state in the K8 system.
StutterTime – RW – 8 bits – [PM_Reg:8Bh]
Field Name
Bits
Default
Description
StutterTime 7:0
00h
LDTSTP#
duration in 1us increment
StutterTime register for ACPI C state in the K8 system.
StpClkDlyTime – RW – 8 bits – [PM_Reg:8Ch]
Field Name
Bits
Default
Description
StpClkDlyTime
7:0
00h
STPCLK# deassertion delay in number of OSC clocks for S1
resume in K8 system.
StpClkDlyTime register for ACPI S state
MiscEnable8D – RW – 8 bits – [PM_Reg:8Dh]
Field Name
Bits
Default
Description
PmeMsgEn
0
0b
Set to 1 to enable PmeTurnOff/PmeMsgAck handshake
SlpS2En
1
0b
Set to 1 to enable GPM9 as SLP_S2 output
AzRstEn
2
0b
Set to 1 to enable GPM8 as AZ_RST# output
DprStpEn
3
0b
Set to 1 to enable DPRSTP# output
Ac97PciClkEnB
4
0b
Clear to 0 to enable gating of the ac97 internal clock
LongReset
5
0b
Set to 1 will cause all reset to be 6ms longer
EffMaskEn
6
0b
(Set to 1 for the P4 system and leave it 0 for K8 system).
On the P4 platform, right after the SB exits from the C state,
the LVL read will have no effect until the previous break event
has been cleared. Setting the bit will prevent the SB from
sending the STPCLK# message to the NB during such time.
On the K8 platform the bit has no meaning and must be 0.
Reserved 7
0b
AbPmeCntl register
FakeAsr– RW – 8 bits – [PM_Reg:8Eh]
Field Name
Bits
Default
Description
FakeAsr 7:0
00h
Fake
alternate
status
FakeAsr register
FakeAsrEn– RW – 8 bits – [PM_Reg:8Fh]
Field Name
Bits
Default
Description
FakeAsrEn
0
0b
FakeAsr enable. If set, SB will return a fake status (defined in
PMIO_8Eh) when IDE DMA is actively busy and software tries
to read the status from the IDE device
UseBypassRom
1
0b
When this bit is set, it will override the ROM straps and use
bits 3:2 of this register to determine which type of ROM to use.
This is for BIOS debugging purpose or for if system desires to
have multiple BIOS on board
BypassRomSel
3:2
00b
These two bits will override the two ROM strap pins.
00 – LPC ROM
10 – FWH ROM
11 – SPI ROM
01 – PCI ROM (not used after A13)
BmReqPopUpEn
4
0b
When set (along with C state PopUp enabled), BmReq# input
will not cause BM_STS to be set; instead, it will simply act just
like AllowLdtStop and cause the C state machine to pop-up to
C2. This bit is only valid under K8 CPU configuration.
