©2008 Advanced Micro Devices, Inc.

OCHI USB 1.1 and EHCI USB 2.0 Controllers

AMD SB600 Register Reference Manual

Proprietary

Page 57

HcInterruptEnable - 32 bits - [MEM_Reg : 10h]

Field Name

Bits

Default

HCD

HC

Description

RD

3

0b

RW

W

0 - Ignore
1 - Enable interrupt generation due to Resume
Detect.

UE

4

0b

RW

RW

0 - Ignore
1 - Enable interrupt generation due to Unrecoverable
Error.

FNO

5

0b

RW

RW

0 - Ignore
1 - Enable interrupt generation due to Frame Number
Overflow.

RHSC

6

0b

RW

RW

0 - Ignore
1 - Enable interrupt generation due to Root Hub
Status Change.

Reserved 29:7

Reserved

OC

30

0b

RW

RW

0 - Ignore
1 - Enable interrupt generation due to Ownership
Change.

MIE

31

0b

RW

R

A ‘0’ written to this field is ignored by HC. A '1' written
to this field enables interrupt generation due to events
specified in the other bits of this register. This is used
by HCD as a Master Interrupt Enable.

HcInterruptDisable - 32 bits - [MEM_Reg : 14h]

Field Name

Bits

Default

HCD

HC

Description

SO

0

0b

RW

R

0 - Ignore
1 - Disable interrupt generation due to Scheduling
Overrun.

WDH

1

0b

RW

R

0 - Ignore
1 - Disable interrupt generation due to HcDoneHead
Writeback.

SF

2

0b

RW

R

0 - Ignore
1 - Disable interrupt generation due to Start of Frame.

RD

3

0b

RW

R

0 - Ignore
1 - Disable interrupt generation due to Resume
Detect.

UE

4

0b

RW

R

0 - Ignore
1 - Disable interrupt generation due to Unrecoverable
Error.

FNO

5

0b

RW

R

0 - Ignore
1 - Disable interrupt generation due to Frame Number
Overflow.

RHSC

6

0b

RW

R

0 - Ignore
1 - Disable interrupt generation due to Root Hub
Status Change.

Reserved 29:7

Reserved

OC

30

0b

RW

R

0 - Ignore
1 - Disable interrupt generation due to Ownership
Change.

MIE

31

0b

RW

R

A '0' written to this field is ignored by HC. A '1' written
to this field disables interrupt generation due to
events specified in the other bits of this register. This
field is set after a hardware or software reset.

HcHCCA - 32 bits - [MEM_Reg : 18h]

Field Name

Bits

Default

HCD

HC

Description

Reserved 7:0

Reserved

HCCA

31:8

000000h

RW

R

This is the base address of the Host Controller
Communication Area
