User's Guide _______________________________________________________________________

104 __________________________________________________________________ M210619EN-E

Follow the steps below to install the HMT318 probe through a ball valve

assembly. After the installation, the probe should be sitting in the process

chamber or pipeline as shown in Figure 34 on page 103.

1.

Shut down the process if the process pressure is more than 10 bars.

If the pressure is lower there is no need to shut down the process.

2.

Close the ball valve.

3.

Seal the threads on the fitting body; refer to Figure 12 on page 31.

4.

Attach the fitting body to the ball valve and tighten it.

5.

Slide the clasp nut of the probe toward the filter, as far as it will go.

6.

Insert the probe to the fitting body, and manually tighten the clasp

nut to the fitting body.

7.

Open the ball valve.

8.

Push the probe through the ball valve assembly into the process.

If the pressure is high, use the pressing handle that is provided with

the probe. If you push the probe hard without using the handle, you

may damage the cable.

Note that the probe must be pushed so deep that the filter is

completely inside the process flow.

9.

Mark the fitting screw and the clasp nut.

10. Tighten the clasp nut with an open-end wrench a further 50 ... 60º

(ca. 1/6 turn). If you have a suitable torque wrench, tighten the nut

to max 45 ± 5 Nm (33 ± 4 ft-lbs). Refer to Figure 13 on page 32.

NOTE

Take care not to tighten the clasp nut more than 60° to avoid difficulties

when opening it.

If you want to remove the probe from the process, note that you have to

pull the probe out far enough. You cannot close the valve if the groove

on the probe body is not visible.
