Appendix A ____________________ PROBE INSTALLATION KITS AND INSTALLATION EXAMPLES
VAISALA _______________________________________________________________________ 101
Examples of Vapor-Tight Installations with
Cable Gland
RH Probe Installations (for HMT313/317)
0508-026
Figure 32
Cable Installation with Cable Gland AGRO
The following numbers refer to Figure 32 above:
1 = Nut (to be tightened to the body)
2 = Seal
3 = Body and O-ring
Vaisala order code for the cable gland: HMP247CG (see section Spare
Parts and Accessories on page 93).
1
3
2
